GIGABYTE Z690M AORUS ELITE DDR4 MOTHERBOARD

19,600.00

Intel® Z690 AORUS Motherboard with Direct 12+1+2 Phases Digital VRM Design, PCIe 5.0 Design, Fully Covered Thermal Design ,3 x PCIe 4.0 M.2 with Thermal Guard, Intel® 2.5GbE, Rear USB 3.2 Gen2x2 TYPE-C®, RGB FUSION 2.0, Q-Flash Plus



  • Supports 12th Gen Intel®  Core™ Series Processors
  • Dual Channel Non-ECC Unbuffered DDR4, 4 DIMMs
  • Direct 12+1+2 Digital VRM Design with 60A Power Stage* and Tantalum Polymer Capacitor
  • Shielded Memory Routing to Avoid Interference
  • Fully Covered Thermal Design with High Coverage MOSFET Heatsinks
  • Fast Intel® 2.5GbE LAN with Bandwidth Management
  • 3 x Ultra-Fast NVMe PCIe 4.0/3.0 x4 M.2 with Thermal Guard
  • SuperSpeed USB 3.2 Gen2x2 TYPE-C® delivers up to 20Gb/s transfer speeds
  • Pre-installed IO Shield for easy and quick installation
  • RGB FUSION 2.0 with Multi-Zone Addressable LED Light Show Design, Support Addressable LED & RGB LED Strips
  • Smart Fan 6 Features Multiple Temperature Sensors , Hybrid Fan Headers with FAN STOP
  • Q-Flash Plus Update BIOS without Installing the CPU, Memory and Graphics Card

Out of stock

SKU: Z690M AORUS ELITE DDR4 Categories: , Tags: , , , ,

Description

    • CPU
      1. LGA1700 socket: Support for 12th Generation Intel® Core™, Pentium® Gold and Celeron® Processors*
      2. L3 cache varies with CPU

      * Please refer to “CPU Support List” for more information.

    • Chipset
      1. Intel® Z690 Express Chipset
    • Memory
      1. Support for DDR4 5333(O.C.)/ DDR4 5133(O.C.)/DDR4 5000(O.C.)/4933(O.C.)/4800(O.C.)/ 4700(O.C.)/ 4600(O.C.)/ 4500(O.C.)/ 4400(O.C.)/ 4300(O.C.)/4266(O.C.) / 4133(O.C.) / 4000(O.C.) / 3866(O.C.) / 3800(O.C.) / 3733(O.C.) / 3666(O.C.) / 3600(O.C.) / 3466(O.C.) / 3400(O.C.) / 3333(O.C.) / 3300(O.C.) / 3200 / 3000 / 2933 / 2800 / 2666 / 2400 / 2133 MHz memory modules
      2. 4 x DDR4 DIMM sockets supporting up to 128 GB (32 GB single DIMM capacity) of system memory
      3. Dual channel memory architecture
      4. Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode)
      5. Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
      6. Support for Extreme Memory Profile (XMP) memory modules

      (Please refer “Memory Support List” for more information.)

    • Onboard Graphics
      Integrated Graphics Processor-Intel® HD Graphics support:

      1. 1 x HDMI port, supporting a maximum resolution of 4096×2160@60 Hz
        * Support for HDMI 2.1 version and HDCP 2.3.
        ** Support native HDMI 2.1 TMDS compatible ports
      2. 1 x DisplayPort, supporting a maximum resolution of 4096×2304@60 Hz
        * Support for DisplayPort 1.2 version and HDCP 2.3

      (Graphics specifications may vary depending on CPU support.)

    • Audio
      1. Realtek® Audio CODEC
      2. High Definition Audio
      3. 2/4/5.1/7.1-channel
        * To configure 7.1-channel audio, you need to open the audio software and select Device advanced settings > Playback Device to change the default setting first. Please visit GIGABYTE’s website for details on configuring the audio software.
      4. Support for S/PDIF Out
    • LAN
      1. Intel® 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps)
    • Expansion Slots
      1. 1 x PCI Express x16 slot, running at x16 (PCIEX16)
        (The PCIEX16 slot conforms to PCI Express 5.0 standard.)
      2. 1 x PCI Express x16 slot, running at x4 (PCIEX4)
        (The PCIEX4 slot conforms to PCI Express 3.0 standard.)
    • Multi-Graphics Technology
      1. Support for AMD Quad-GPU CrossFire™ and 2-Way AMD CrossFire™ technologies
    • Storage Interface
      CPU:

      1. 1 x M.2 connector (Socket 3, M key, type 2260/2280 PCIe 4.0 x4/x2 SSD support) (M2A_CPU)

      Chipset:

      1. 1 x M.2 connector (Socket 3, M key, type 2260/2280 PCIe 4.0 x4/x2 SSD support) (M2Q_SB)
      2. 1 x M.2 connector (Socket 3, M key, type 2260/2280/22110 PCIe 4.0 x4/x2 SSD support) (M2P_SB)
      3. 6 x SATA 6Gb/s connectors

      Support for RAID 0, RAID 1, RAID 5, and RAID 10
      Intel® Optane™ Memory Ready
      * System acceleration with Intel® Optane™ Memory can only be enabled on the M.2 connectors supported by the Chipset.

    • USB
      Chipset:

      1. 1 x USB Type-C® port on the back panel, with USB 3.2 Gen 2×2 support
      2. 1 x USB Type-C® port with USB 3.2 Gen 2 support, available through the internal USB header
      3. 1 x USB 3.2 Gen 2 Type-A port (red) on the back panel

      Chipset+2 USB 3.2 Gen 1 Hubs:

      1. 6 x USB 3.2 Gen 1 ports (4 ports on the back panel, 2 ports available through the internal USB header)

      Chipset+2 USB 2.0 Hubs:

      1. 8 x USB 2.0/1.1 ports (4 ports on the back panel, 4 ports available through the internal USB headers)
    • Internal I/O Connectors
      1. 1 x 24-pin ATX main power connector
      2. 1 x 8-pin ATX 12V power connector
      3. 1 x 4-pin ATX 12V power connector
      4. 1 x CPU fan header
      5. 1 x water cooling CPU fan header
      6. 3 x system fan headers
      7. 1 x system fan/water cooling pump header
      8. 2 x addressable LED strip headers
      9. 2 x RGB LED strip headers
      10. 3 x M.2 Socket 3 connectors
      11. 6 x SATA 6Gb/s connectors
      12. 1 x front panel header
      13. 1 x front panel audio header
      14. 1 x USB Type-C® header, with USB 3.2 Gen 2 support
      15. 1 x USB 3.2 Gen 1 header
      16. 2 x USB 2.0/1.1 headers
      17. 2 x Thunderbolt™ add-in card connectors
      18. 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only)
      19. 1 x serial port header
      20. 1 x reset button
      21. 1 x Q-Flash Plus button
      22. 1 x reset jumper
      23. 1 x Clear CMOS jumper
    • Back Panel Connectors
      1. 1 x USB Type-C® port, with USB 3.2 Gen 2×2 support
      2. 1 x USB 3.2 Gen 2 Type-A port (red)
      3. 4 x USB 3.2 Gen 1 ports
      4. 4 x USB 2.0/1.1 ports
      5. 1 x HDMI port
      6. 1 x DisplayPort
      7. 1 x RJ-45 port
      8. 1 x optical S/PDIF Out connector
      9. 2 x audio jacks
    • I/O Controller
      1. iTE® I/O Controller Chip
    • H/W Monitoring
      1. Voltage detection
      2. Temperature detection
      3. Fan speed detection
      4. Water cooling flow rate detection
      5. Fan fail warning
      6. Fan speed control
        * Whether the fan (pump) speed control function is supported will depend on the fan (pump) you install.
    • BIOS
      1. 1 x 256 Mbit flash
      2. Use of licensed AMI UEFI BIOS
      3. PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
    • Unique Features
      1. Support for APP Center
        * Available applications in APP Center may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications.
        @BIOS
        EasyTune
        Fast Boot
        Game Boost
        ON/OFF Charge
        RGB Fusion
        Smart Backup
        System Information Viewer
      2. Support for Q-Flash Plus
      3. Support for Q-Flash
      4. Support for Xpress Install
    • Bundled Software
      1. Norton® Internet Security (OEM version)
      2. cFosSpeed
    • Operating System
      1. Support for Windows 11 64-bit
      2. Support for Windows 10 64-bit
    • Form Factor
      1. Micro ATX Form Factor; 24.4cm x 24.4cm

Additional information

Weight 2.5 kg
