Features
Meshify strikes an aggressive pose in the Fractal Design lineup with unparalleled cooling performance and a defiant new look. Like black diamond facets, the angular asymmetry of the Meshify C Mini – Dark TG carves a space uniquely its own as a new force in high-airflow design.
- Streamlined high-airflow design
- Performance and capacity of a larger tower in a compact mATX designed tower
- Angular mesh front panel maximizes air intake
Significantly smaller, but just as cool
Tempered glass with a distinctive tint completes the stealth-inspired black-on-black aesthetic with exceptional style.
The Meshify C Mini – Dark TG has a remarkably compact footprint with the high-end component support of a larger tower, and with six fan mounts and multi-radiator liquid cooling capability, it has the cooling capacity to match. When performance is top priority and compromise is not an option, Meshify has you covered in style.
Streamlined high-airflow design
- Angular mesh front panel maximizes air intake
- Two preinstalled Fractal Design Dynamic X2 GP-12 120 mm fans deliver optimum airflow with minimal noise
- Open interior layout creates an unobstructed airflow path from front intake to rear exhaust
- Flexible storage options with room for up to five drives
Full interior visiblity
Tinted tempered glass side panel for a clean looking exterior with full interior visibility
Distinctive style
With stealthy black-on-black aesthetic
Easy-to-clean filters
Front, top and base with full PSU coverage and convenient front access
Open to suggestions
- Sturdy steel drive trays with vibration-dampening rubber grommets cushion hard drives for smooth, quiet and reliable operation
- Full length power supply shroud conceals drive cage and excess cabling for unrestricted airflow and a clean looking interior
- Up to 35 mm of space behind motherboard plate with grommeted pass-throughs for clean cable routing
Room for flexibility
- Sturdy steel drive trays with vibration-dampening rubber grommets cushion hard drives for smooth, quiet and reliable operation
- Flexible storage options with room for up to five drives
- Up to 35 mm of space behind motherboard plate with grommeted pass-throughs for clean cable routing
Improved air cooling
- Whatever your liquid cooling ambitions may be, Meshify C can make it happen with support for radiators up to 280 mm in the front and 240 mm up top.
- Open interior layout creates an unobstructed airflow path from front intake to rear exhaust.
- Even the largest enthusiast-class GPUs leave plenty of room for thick dual-fan rads in the front. The adjustable drive cage can be moved or removed to fit even the lengthiest heavy-duty PSUs.
Specifications
| Product Code | FD-CA-MESH-C-MINI-BKO-TGD |
| 3.5″ or 2.5″ Drive capacity | 2 |
| Dedicated 2.5″ drive capacity | 3 |
| Expansion slots | 5 |
| Front ports | 2x USB 3.0, Audio I/O, Power button, Reset button |
| Total fan mounts | 7 |
| Front fan | 3x 120 mm or 2x 140 mm (1x Dynamic X2 GP-12 included) |
| Top fan | 2x 120/140 mm |
| Rear fan | 1x 120 mm (1x Dynamic X2 GP-12 included) |
| Bottom fan | 1x 120 mm |
| Dust filters | Bottom fan + PSU, Front fans, Top fans |
| Cable routing grommets | Yes |
| Fixed velcro straps | Yes |
| Captive thumbscrews | Both side panels, SSD brackets |
| Left side panel | Tempered glass panel |
| Right side panel | Steel |
| Compatibility | |
| Power supply type | ATX |
| Motherboard compatibility | mATX, ITX |
| Front radiator | 120/240 mm, 140/280 mm (max width 144 mm) |
| Top radiator | 120/240 mm (max component height on motherboard 40 mm) |
| Rear radiator | 120 mm (max width 125 mm) |
| PSU max length | 175 mm |
| GPU max length | 315 mm with front fan mounted |
| CPU cooler max height | 172mm |
| Cable routing space | 15-35 mm |
| Dimensions | |
| Case dimensions (LxWxH) | 395 x 212 x 399 mm |
| Case dimensions w feet/protrusions/screws | 409 x 217 x 412 mm |
| Net weight | 6.28 kg |
| Package dimensions (LxWxH) | 502 x 295 x 484 mm |
| Package weight | 7.41 kg |
| Volume | 33.4 Liters |
| Warranty | 2 Years |
| Note | *** Features, Specifications, Price are subject to change without notice. |
