Specifications
Product Code | FD-C-MES2X-02 |
3.5″/2.5″ Universal drive mounts | 6 included, 18 positions total + 2 Multibrackets |
Dedicated 2.5″ drive mounts | 2 included, 5 positions total |
Expansion slots | 9 + 3 |
Front interface | 1x USB 3.1 Gen 2 Type-C, 2x USB 3.0, Audio I/O, Power button, Reset button |
Total fan mounts | 11x 120 mm or 9x 140 mm |
Front fan | 4x 120 mm or 3x 140 mm, (2x Dynamic X2 GP-14 included) |
Top fan | 4x 120 mm or 3x 140 mm |
Rear fan | 1x 120/140 mm, (1x Dynamic X2 GP-14 included) |
Bottom fan | 2x 120/140 mm |
Dust filters | Top, front and bottom |
Fixed velcro straps | Yes |
Cable routing grommets | Yes |
Captive thumbscrews | HDD, SSD and PSU brackets |
Left side panel | Tempered glass dark tint |
Right side panel | Steel |
Compatibility | |
Power supply type | ATX |
Motherboard compatibility | E-ATX / ATX / mATX / Mini-ITX / EE-ATX / SSI-CEB / SSI-EEB |
PSU max length | 250 mm (both HDD cages installed) |
GPU max length | Storage layout: 359 mm Open layout: 549 mm (524 mm w/ front fan) |
CPU cooler max height | 185 mm |
Front radiator | Up to 480/420 mm |
Top radiator | Up to 480/420 mm |
Rear radiator | 120 mm |
Bottom radiator | Up to 240/280 mm |
Cable routing space | 30 mm |
Dimensions | |
Case dimensions (LxWxH) | 600 x 240 x 566 mm |
Case dimensions w feet/protrusions/screws | 588 x 240 x 547 mm |
Net weight | 14.1 kg |
Package dimensions (LxWxH) | 651 x 330 x 684 mm |
Gross weight | 16.4 kg |
Volume | 77,2 liters |
Warranty | 2 Years |
Note | *** Features, Specifications, Price are subject to change without notice. |
