Fractal Design Define 7 Black/White Tempered Glass Clear Tint

17,790.00

  • • New chassis design opens up to fully expose the case interior
  • • Anodized aluminum front panel with reversible dual-handed hinges
  • • Multibracket converts unused fan positions to HDD, SSD or pump mounts

In stock

SKU: FD-C-DEF7A-05 Categories: , Tags: , , ,

Description

Specifications

  • 3.5″/2.5″ Universal drive brackets
    6 included, 14 positions total
  • Dedicated 2.5″ drive brackets
    2 trays included, 4 positions total
  • 5.25” drive mounts
    1
  • Expansion slots
    7 + 2
  • Front ports
    1 x USB 3.1 Gen 2 Type-C, 2 x USB 3.0, 2 x USB 2.0, Audio I/O, Power button, Reset button
  • Total fan mounts
    9 x 120/140 mm
  • Front fan
    3 x 120/140 mm (2 x Dynamic X2 GP-14 included)
  • Top fan
    3 x 120/140 mm
  • Rear fan
    1 x 120/140 mm (1 x Dynamic X2 GP-14 included)
  • Bottom fan
    2 x 120/140 mm
  • Dust filters
    Top, 2 x front, full length bottom
  • Fixed velcro straps
    Yes
  • Cable routing grommets
    Yes
  • Captive thumbscrews
    HDD brackets, SSD brackets, PSU bracket
  • Left side panel
    Tempered glass
  • Right side panel
    Industrial sound-damped steel

Compatibility

  • Motherboard compatibility
    E-ATX (max 285 mm) / ATX / mATX / mITX
  • Power supply type
    ATX
  • PSU max length
    250 mm (with HDD cage installed)
  • GPU max length
    Storage layout: 315 mm – Open layout: 491 mm (467 mm w/ front fan)
  • CPU cooler max height
    185 mm
  • Front radiator
    Up to 360/280 mm
  • Top radiator
    Up to 360/420 mm
  • Rear radiator
    120 mm
  • Bottom radiator
    Up to 240/280 mm
  • Cable routing space
    30 mm
  • Vertical GPU Support (with Flex VRC-25)
    65mm total clearance, standard 2-slot GPU (<38mm thickness) recommended for optimum cooling

Dimensions

  • Case dimensions (LxWxH)
    547 x 240 x 475 mm
  • Case dimensions w/o feet/protrusions/screws
    533 x 240 x 451 mm
  • Package dimensions (LxWxH)
    558 x 363 x 641 mm
  • Net weight
    13.45 kg
  • Package weight
    15.94 kg
  • Volume
    57.7 liters

Other

  • Warranty
    5 Years
  • Package contents
    Define 7 case. Accessory box. User manual. Ventilated top. 4 x HDD/SSD trays (for a total of 6)
  • EAN
    Black/White – 7340172702238. White – 7340172702245
  • UPC
    Black/White – 843276102234. White – 843276102241
  • JAN
    Black/White – 4537694275880. White – 4537694275897
  • Product code
    Black/White – FD-C-DEF7A-05. White – FD-C-DEF7A-06
