Arctic P12 PWM PST ARGB Cabinet Fan (Triple Pack)

Description

Features:

RGB FOR FULL COLOUR CONTROL

The P12 PWM PST A-RGB 0dB has 12 digital A-RGB LEDs in the fan scar. These can be controlled independently of each other and are compatible with the common A-RGB standards of leading motherboard manufacturers. The fan can thus be fully illuminated directly via the A-RGB mainboard connector or via an external controller and synchronised with the illumination of other hardware.

0dB Mode – Zero RPM

The speed of the fan can be throttled down to standstill via PWM. This allows silent operation in IDLE and at the same time guarantees maximum performance when required.

MAXIMUM SMOOTHNESS, MINIMUM VIBRATION

The operating noise of the newly developed ARCTIC motor is barely perceptible even at the lowest speed. In addition, the P12 PWM PST A-RGB 0dB has rubberised contact surfaces and thus reduces audible vibrations to a minimum.

OPTIMISED FOR HIGH STATIC PRESSURE

The P12 PWM PST A-RGB 0dB operates with a focused airflow and a high static pressure. The fan thus guarantees extremely efficient cooling, even with increased air resistance, and is therefore suitable for use on heat sinks, radiators and filters.

0 TO 2000 RPM CONTROLLED VIA PWM PST

With a wide speed range and the innovative PWM Sharing Technology (PST), the fan speed of the P12 PWM PST A-RGB 0dB can be controlled synchronously with all other fans. This reduces noise to a minimum while guaranteeing maximum cooling performance.

HIGH QUALITY BEARING

Thanks to an alloy/lubricant combination developed in Germany, friction within the bearing is reduced and greater efficiency is achieved. In this way, less heat develops, less bearing noise is generated and the service life of the fan is extended.





Specifications:

Performance
Fan Speed	0 – 2000 rpm
Airflow	48.8 CFM/ 82.91 m³/h
Static Pressure	1.85 mm H₂O
Noise Level	0.3 Sone
Operating Ambient Temperature	0 – 40 °C
Fan
Fan Frame	Standard
Control Type	PWM PST
Connector	4-Pin-Connector + 4-Pin-Socket
Fan Bearing	Fluid Dynamic Bearing
Electric Characteristics
Typical Voltage	12 V DC
Starting Voltage	5 V
Current/ Voltage	0.12 A / 12 V
Cable Lenght	400 mm
Size & Weight
Length	120 mm
Width	120 mm
Height	15 mm
Weight	131 g
Warranty	6 Years
Note	*** Features, Price, Specifications are subject to change without notice.
