Features:
Long Service Life
The Fluid Dynamic Bearing comes with an oil capsule that avoids lubricant leakage. Thus this bearing is as quiet as a sleeve bearing but comes with a significantly higher service life
Innovative Design Enables Quiet and Efficient Ventilation
The innovative design of the fan blades improves the air flow and facilitates a highly efficient ventilation. The impeller was designed with a focus on minimzing the noise level yet delivering the desired airflow and pressure.
Two Way installation
Blow warm air out of the case
Draw cool air into your case
Specifications:
| Performance | |
| Fan Speed | 1350 rpm |
| Airflow | 53 CFM/ 90.1 m³/h |
| Static Pressure | 1.00 mm H₂O |
| Noise Level | 0.3 Sone |
| Operating Ambient Temperature | 0 – 40 °C |
| Fan | |
| Fan Frame | Standard |
| Control Type | Fixed Speed |
| Connector | 3-Pin-Connector |
| Fan Bearing | Fluid Dynamic Bearing |
| Electric Characteristics | |
| Typical Voltage | 12 V DC |
| Starting Voltage | 2.7 V |
| Current/ Voltage | 0.12 A / 12 V |
| Cable Lenght | 400 mm |
| Size & Weight | |
| Length | 120 mm |
| Width | 120 mm |
| Height | 25 mm |
| Weight | 107 g |
| Warranty | 6 Years |
| Note | *** Features, Price, Specifications are subject to change without notice. |
